Product Description:
The 12G SDI Uncompressed 4K Fiber Extender provides reliable, long-distance, real-time video transmission for broadcast and professional AV applications. Designed to support 12G-SDI uncompressed 4K video, embedded audio, and bi-directional data, this 12G SDI fiber extender ensures lossless signal transport over fiber optics, up to 20 kilometers. With advanced FPGA video processing technology, the extender converts SDI video into optical signals, ensuring high-speed transmission with no frame loss or image degradation. The integrated clock recovery technology guarantees smooth and zero frame loss during long-distance transmission, ideal for critical applications like live broadcasting and professional AV setups.
Product Features:
- Supports digital SDI HD uncompressed optical fiber long-distance transmission
- Support 12G/HD/SDSDI input adaptive
- Support resolution up to 1080P60HZ, backward compatible
- Removable SFP module LC optical port (Multiple FC optical ports)
- Support standard 10KM module, optional 20/40/80KM transmission distance
- Supports the design of a plug-in chassis
- Supports the combination of rack and box
- Support multiplex administration
Technical Parameters:
| Video | Signal standard | SMPTE ST-2082,SMPTE ST-2081 ,SMPTE 424M, SMPTE 292M, SMPTE 259M, DVB-ASI | | | Data rate | 270Mbit/s-1.48Gbit/s-2.97Gbit/s-6Gbit/s-12Gbit/s | | | Cable equalization | 250m @ 270Mbit/s, 140m @ 1.5Gbit/s, 100m@2.97Gbit/s,12Gbit/s 80m | | | Signal amplitude | 800mV±10% | | | Quiver | >0.2UI | | | Support resolution | 2160P60/50/30HZ1080P60HZ/50HZ;1080P30HZ/25HZ/24HZ; | | | Video interface | 75-5Ω BNC connector | | | Impedance | 75 ohm | | RS485 | Interface | 3PIN Phoenix terminal | | | Signal direction | Single - way bidirectional transmission, multi - way unidirectional transmission | | | Baud rate | Adaptive, up to 115200bps | | Optical Fiber | Optical fiber interface | Single channel: LC port Rack: FC port (LC/ST/SC) Optional | | | Fiber type | Single mode/multi-mode | | | Wave length | Single mode 1310-155nm | | | Interface bandwidth | 12Gbps | | | Transmission distance | Standard 10KM,20/40/60/80KM optional | | Others | Power source | Single-channel: DC12V/1A 1U/2U/4U rack AC220V | | | Maximum power consumption | MAX 4W | | | Temperature | Operating temperature: 0℃ ~ +70℃ | | | Humidness | Working humidity: 5% ~ 90% | | | Overall dimension | Refer to the equipment size drawing | |
Application and Scene:
The 12G SDI Uncompressed 4K Fiber Extender is widely used across various industries that demand high-quality, real-time video transport. Key applications include:
Broadcast Television: Provides 4K UHD video transport for remote production, live broadcasts, and mobile studios.
Medical Imaging: Essential for medical education, surgical procedures, and live video feeds where high clarity is critical.
Video Conferencing: Supports real-time 4K video conferencing, ensuring clear video and audio quality for corporate communications.
Education & Training: Perfect for live streaming, remote learning, and distance education that require high-definition video.
Surveillance Systems: Ideal for long-distance security camera feeds and surveillance networks that require 4K video resolution.
