Product Description:
This professional HDMI extender 4K 60Hz over fiber optic is built to deliver ultra-high-definition video and audio signals across distances of up to 10KM using single-mode fiber. It supports full HDMI 2.0 and RS232 data transmission, ensuring seamless long-range connectivity for critical applications. Designed with excellent EMI resistance, a compact footprint, and lightweight construction, this HDMI over fiber optical extender offers outstanding reliability and safety. It’s widely deployed in high-performance AV scenarios such as control rooms, transportation monitoring, broadcasting centers, medical teaching, video conferencing, and education live streaming. Whether you need a 4K HDMI optical extender or a future-proof HDMI 4K extender for your installation, this solution guarantees stable 4096×2160@60Hz signal delivery, making it an ideal choice for integrators and system designers seeking efficient HDMI fiber optic extension.
Key Features:
- Complies with HDMI 2.0b, HDCP 2.2, and DVI 1.0 standards for maximum compatibility.
- Supports resolutions up to 4K2K@50/60Hz (4:4:4), with full support for 4096×2160@60Hz, delivering crystal-clear uncompressed video.
- Achieves 18Gbps bandwidth for seamless high-speed video data transmission—ideal for HDMI 4K extender applications.
- Equipped with LED indicators for real-time status monitoring and diagnostics.
- The transmitter features a loop-out port (shared local signal) and external audio embedding for flexible signal integration.
- The receiver supports backup video output and audio de-embedding, enhancing system reliability.
Technical Parameters:
| Power Supply | Single-circuit: DC 12V/1A |
| Interface | HDMI-A interface |
| Bandwidth | High-Bandwidth |
| Product Name | 4K@60Hz HDMI Fiber Optic Extender |
| Storage Temperature | -20°C~60°C / -4°F~104°F |
| Signal Transmission | Optical Fiber |
| Compatibility | Universal |
| Audio Support | Stereo |
| Product Category | Fiber Optic Extender |
| Operating Temperature | 0°C~40°C / 32°F~104°F |
| Product Name | 4K @60Hz HDMI Optical Extender |
Applications:
This HDMI 4K optical extender is designed for scenarios requiring high-performance, long-distance 4K video and audio transmission over fiber. With uncompressed 4K@60Hz signal delivery, it offers a stable and reliable solution for various professional AV applications.
Main Application Scenarios:
- Broadcast and television studios
- Video conferencing systems
- Medical imaging and teaching environments
- Educational recording and live streaming
- Command and control centers
- Exhibition and projection systems
- Transportation and rail monitoring
- Security and surveillance systems
